Automatic Chicken Cow Feed 25kg 50kg Weighing Filling Packaging Machine

Short Description:


Product Detail

Contact us

FAQ

Product Tags

Introduction
This series of weighing machine is mainly used for quantitative packaging, manual bagging and inductive feeding of granular products such as washing powder, monosodium glutamate, chicken essence, corn and rice. It has high precision, fast speed and durability.
The single scale has one weighing bucket and the double scale has two weighing buckets. The double scales can discharge materials in turn or in parallel. When discharging materials in parallel, the measuring range and error are doubled.
DCS series gravity feeder packing machines are used to weighing and packing granules materials such as animal feed, granule fertilizer, urea, seed, rice, sugar, beans, corn, peanut, wheat, PP, PE, plastic particles, almond, nuts, silica sand etc.
The bag can be closed by heat sealing for lining/plastic bags and sewing (thread stitching) for woven bags, paper bags, kraft bags, sacks etc.

Product pictures

machines截图2 machines截图1

Working principle
The granule packaging machine with single hopper needs to manually wear the bag, manually put the bag on the discharging spout of the packing machine, toggle the bag clamping switch, and the control system will drive the cylinder after receiving the bag clamping signal to drive the bag clamp to clamp the bag and start feeding at the same time The mechanism sends the material in the silo into the weighing hopper. After reaching the target weight, the feeding mechanism stops feeding, the silo is closed, and the material in the weighing hopper is filled into the packaging bag by gravity feeding. After the filling is completed, the bag clamper will automatically open, and the filled packaging bag will automatically fall onto the conveyor, and the conveyor will be transported back to the sewing machine. The bag will be manually assisted to sew and output to complete the packaging process.

working process

Parameters

Model DCS-GF DCS-GF1 DCS-GF2
Weighing Range 1-5, 5-10, 10-25, 25-50 Kg/bag, customized needs
Precisions ±0.2%FS
Packing Capacity 200-300bag/hour 250-400bag/hour 500-800bag/hour
Power supply 220V/380V, 50HZ, 1P/3P (Customized)
Power (KW) 3.2 4 6.6
Dimension (LxWxH)mm 3000x1050x2800 3000x1050x3400 4000x2200x4570
The size can be customized according to your site.
Weight 700kg 800kg 1600kg

The above parameters are only for your reference, the manufacturer reserves the right to modify the parameters with the development of the technology.


Functional features

1. Manual assistance is needed for bag loading, automatic weighing, bag clamping, filling, automatic conveying and sewing;
2. Gravity feeding mode is adopted to ensure the bagging speed and accuracy through instrument control;
3. It adopts high precision sensor and intelligent weighing controller, with high precision and stable performance;
4. The parts in contact with materials are made of stainless steel with high corrosion resistance;
5. Electrical and pneumatic components are imported components, long service life and high stability;
6. The control cabinet is sealed and suitable for harsh dust environment;
7. Material out of tolerance automatic correction, zero point automatic tracking, overshoot detection and suppression, over and under alarm;
8. Optional automatic sewing function: photoelectric induction automatic sewing after pneumatic thread cutting, saving labor.
Bag type:
Our packing machine can working with the automatic sewing machine closed the woven bags, kraft bags, paper bags or sacks by thread stitching and automatic thread cut.
Or the heat sealing machine for lining/ plastic bags sealing.

包装形态

Application

物料截图1 物料截图2

Some projects show

工程图1 吨袋卸料工程案例 666

Company profile

通用电气配置 包装机生产流程

company profile
