Full Automatic Cement Bagging Machine Powder Bag Forming Filling Sealing Machine

Short Description:


Product Detail

Contact us

FAQ

Product Tags

Product overview


Performance characteristics:

·It is composed of bag making packaging machine and screw metering machine
·Three side sealed pillow bag
·Automatic bag making, automatic filling and automatic coding
·Support continuous bag packaging, multiple blanking and punching of handbag
·Automatic identification of color code and colorless code and automatic alarm

Packing Material:

Popp / CPP, Popp / vmpp, CPP / PE, etc.

Screw metering machine:

1660206793430 vffs细节

Technical parameters

Model DCS-520
Length of bag 50-390mm(L)
Width of bag 50-250mm(W)
Width of film 520mm
Packing speed 15-60bag/min
Air pressure 0.65mpa
Air consumption 0.3m³/min
Power supply 220VAC/50/60Hz
Power 2.2KW
Dimension 1080(L) ×1500(W) ×1600(H)mm
Weight 650Kg

Applicable materials:
Automatic packaging of powder materials, such as starch, milk powder, chicken powder, spices, concentrated washing powder, Pepper powder. Chili powder, Spices Powder, masala powder, Leaven Enzyme Soda Powder, Wheat Flour, Almond powder Tapioca Starch, Cornmeal, Cocoa Powder.

powder 2 powder1

Technical features:
Multi language interface, easy to understand.
Stable and reliable PLC program system.
Can store 10 recipes.
Servo film pulling system with accurate positioning.
Vertical and horizontal sealing temperature is controllable, suitable for all kinds of films.
Various packaging styles.
Synchronization of filling, bag making, sealing and coding.

VFFS.
It is for forming pillow bag, gusset bag, four edge bags and fill powder from auger filler.
Printing date, sealing and cutting.
We have 320VFFS,420VFFS,520VFFS,620VFFS,720VFFS,1050VFFS for option

jietu-vffs

Other Auxiliary Equipment

10 Other Other related equipment
